SP6T Loaded Coaxial Switch

The S-band Transmit-Receive Antenna consists of a transmit antenna, a receive antenna, a transmit-band filter and a receive-band filter. The transmit frequency bands are 2X00–2X80 MHz and 3X00–3X00 MHz, while the receive frequency band is 20XX–21XX MHz. It realizes the transmission and reception of right-hand circularly polarized (RHCP) and left-hand circularly polarized (LHCP) signals. The isolation between transmit and receive channels is 58 dB.The product design with SMA Female RF interfaces.

Inquiry

Download

E-mail：sylvialee@mwglobe.com ，sales@mwglobe.com

Detailed Description

Description

The SP6T loaded coaxial switch is a signal switching device designed to selectively route a single input signal to any one of six different paths.It operates over the frequency range of DC~67 GHz, with insertion loss less than 1.2 dB, VSWR less than 1.8, and isolation greater than 60 dB.The product equipped with 1.85 female RF interfaces.

Technical Specifications

Parameters			Min.	Typ.	Max.	Units
Frequency Range			DC		67	GHz
Insertion Loss	DC~18 GHz				0.4	dB
	18~26.5 GHz				0.5
	26.5~40 GHz				0.6
	40~50 GHz				0.8
	50~67 GHz				1.2
VSWR Output	DC~18 GHz				1.3
	18~26.5 GHz				1.4
	26.5~40 GHz				1.5
	40~50 GHz				1.7
	50~67 GHz				1.8
Isolation	DC~18 GHz		80			dB
	18~26.5 GHz		75
	26.5~40 GHz		60
	40~50 GHz		60
	50~67 GHz		55
Operating Temperature Range		-55			+85	˚C
Weight					0.5	Kg
